Stainless Steel Gate Valve
Materials: CF8, CF8M
Dimension: 1/4"-4"
Working pressure: 200 PSI
End types: Threaded(NPT, BSP, BSPT, DIN2999)
This valve is a fully flanged unit that is designed to be bolted into the pipeline using flange connections. Both stainless steel and cast steel material avaible for this type.
Specification Details
Design Std: DIN 3352, DIN EN 12516-2
Size:DN50--DN600
Body: Cast Steel WCB, GS-C25, Stainless Steel A351-CF8, CF8M, CF3, CF3M
Wedge: Stainless steel 304,316
Pressure Rating: PN25, PN40
Seat: Stainless Steel - AISI 420, 304,316
Bolted Bonnet; Outside Screw & Yoke
Face to Face:EN558-1 Series 15 (DIN 3202 F5)
Flanges drilled: Flange Drilling:DIN2501 PN25-40
Leakage rate B according to EN 12266-1
Temperature range: -10°C/+180°C
If you want to know more details, please send an email to us to solidvalves@aliyun.com. |
