1. Size: 1/2"-4"
2. Pressure: 1.6 Mpa - 2.0Mpa
3. Thread: NPT, BSP, BSPT
4. Material: Brass body, Brass bonnet, Brass stem, PTFE seal, brass gland, brass nut, steel handle.
5. Working Medium: Water, oil, gas
6. Working temperature: -20°C ~120°C
Material:
| Part |
Material |
| Body |
Brass: |
Hpb 57-3 |
Hpb 59-1 |
CW617N |
CW614N |
DZR |
lead free brass |
| Bonnet |
Brass as above |
| Ball |
Brass with chrome plated |
Iron with chrome plated |
| Stem |
Brass with chrome plated or not |
Iron with chrome plated or not |
| Sealing |
PTFE(Teflon) |
Plastic |
| Handle |
|
Iron |
Stainless steel |
Zinc |
With plastic coated |
| Nut |
|
Iron |
Zinc |
Stainless steel |
Brass |
| O-Ring |
NBR |
Technics:
| Temperature: -20°C≤T≤150°C |
| Pressure: P≤3.0MPa=30bar=435psi |
| Medium: Water,Oil,Gas,etc. |
| Thread: F×F threaded as ISO228,BSP,NPT,UNION,ect. |
| Full port. |
| Surface treatment: brass yellow,nickel plated,chrome plated. |
If you want to know more details, please send an email to us to solidvalves@aliyun.com. |
|
| |
|
