Standard: EN593/ ISO 5752 /BS5155/AWWA C504
Flange drilling is according to DIN 2501, BS4504, ANSI B16.1
Working pressure: 10bar/16bar/25bar
Testing pressure:
Shell: 15bar/24bar/37.5bar
Seal: 11bar/17.6bar/27.5bar
Material:
Body: DI/CI /Carbon Steel/Stainless Steel
Disc: DI/Stainless steel 304/316, AL-Bronze
Shaft: Stainless steel410/416/420, Seat: EPDM/NBR
Coating: Internal and external with fusion bonded epoxy coating min250μm
| Standard |
EN593/ ISO 5752 /BS5155/AWWA C504
Flange drilling is according to DIN 2501, BS4504, ANSI B16.1
|
| Type |
Double Flange Eccentric, Double Flange Concentric, Water type ,
Lug type , U type , Grooved type
|
| Material |
Body : DI/CI /Carbon Steel/Stainless Steel
Disc: DI/Stainless steel 304/316,AL-Bronze
Shaft : Stainless steel410/416/420
Seat : EPDM/NBR
|
| Coating |
Internal and external with fusion bonded epoxy coating min250μm |
If you want to know more details, please send an email to us to solidvalves@aliyun.com. |
|
