Standard: EN1074-4, BS, ANSI
Working pressure: 10bar/16bar/25bar
Testing pressure:
Shell: 15bar/24bar/37.5bar
Seal: 11bar/17.6bar/27.5bar
Material: Ductile iron GGG40/50 /Cast Iron GG25/Carbon Steel
Float ball: SS304, ABS or NBR
Coating: Internal and external with fusion bonded epoxy coating. min250μm or liquid epoxy painting.
| Standard |
EN1074-4, BS , ANSI |
| Type |
Single orifice type, double orifice type, triple function |
| Material |
Ductile iron GGG40/50 /Cast Iron GG25/Carbon Steel,
float ball: SS304, ABS or NBR
|
| Coating |
Internal and external with fusion bonded epoxy coating. min250μm or liquid epoxy painting |
.jpg)
If you want to know more details, please send an email to us to solidvalves@aliyun.com. |
|
